DOLPHIN-SMART
SKU: 124750
Dolphin Smart is our LED moving head beam light built to perform at the highest level. It comes loaded with 14 color filters plus white, infinite CMY color mixing for smooth, uniform color, and a blazing 60,000 lux at 10 meters.
It's compact and lightweight, but don't let that fool you. You're getting high-precision pan and tilt scanning, infinite tilt rotation, and fast response that keeps up with whatever you throw at it. Whether you're lighting a theater, TV studio, major concert, or a big arena event, Dolphin Smart is ready for it.
FEATURES
DOLPHIN SMART is an LED moving head light that combines a pure beam with a gobo effect
High-precision optical lenses with oil-mist prevention design
174mm output lens diameter for stable and high-efficiency illumination
360° infinite Tilt axis rotation for flexible positioning
CMY color mixing system + 14-slot color wheel for rich chromatic options
2 rotating/fixed gobo wheels (7 rotating + 7 static gobo slices)
Overlapping 8-facet/24-facet prisms with frost and dynamic layering effects
Rapid effect switching for immersive visual spectacles
IP66-rated housing for outdoor concerts, rental events, and theme park shows
Tool-free quick installation and DMX512, RDM control compatibility
5-Year Warranty
Full parts and labor coverage
U.S. Support
Provided by Blizzard Lighting
DOLPHIN-SMART
Infinite CMY possibilities
technical
specifications
optical
Light source: 300W white LED module
Beam angle: 1.77° (φ6.5mm Beam reducer) / 1.3° (φ5mm Beam reducer)/ 0.8° (φ3mm Beam reducer)/ 0.5° (φ1.5mm Beam reducer), switchable
Optical lens: High-transmittance coating, φ174mm
Illuminance: 60,000 Lux@10m
color
Color temperature: 7400K ±250K
Color Rendering Index: RA≥70
LED source life expectancy: 50,000 hours*
CMY infinite color mixing
14 color filters + blank: Bidirectional color rainbow, dual-color gradient, color wheel rotation, random modes
7 fixed gobos + blank + 7 removable glass gobos (self-rotation/flow/jitter effects)
effects
Prism: 24-facet prism + 8-facet prism, bidirectional rotation
Frost effect: Light Frost
Dimming: 0-100% linear dimming with uniform spot
Strobe speed: 0.5-25 times/sec
LED refresh rate: 1000Hz~25KHz
control
Control channels: 23CH (see channel chart for details)
Protocols: DMX512, RDM, Art-Net (optional)
Data connection: 3-pin or 5-pin
Display: LCD screen
software
Software upgrade via DMX signal
x/y angle of motion
Pan axis: 540° (8bit/16bit precision)
Tilt axis: Infinite rotation
Auto-correction reset function
Fixed Lock: Tilt lock
power
Input voltage: AC 100-240V 50/60Hz
Max power: 562W
Power factor: 0.99
Max current: 2.55A/220V, 5.62A/100V
size & weight
Product size: 353X232X621mm
Net weight: 22.0KG
Carton packaging (default): 425X305X750mm
Gross weight: 26.1KG
included accessories
Power Cable: 1 pc (Part No.: F0200030016)
Signal Cable: 1 pc (Part No.: F0200020008)
Safety Rope: 2 pcs (Part No.: F0200010002)
Lamp Hook: 1 set Lamp comes with a collapsible hook(Part No.: C0499990051)
road case
Fly Case: 650×440×830 mm
others
IP-Rating: IP66
Operating environment: -20℃~45℃
Max surface temperature: ≤60℃
Intelligent temperature control for LED lifespan
Silent fan with three modes: High-brightness/Standard/Silent
